UP Xtreme i12. Celeron® 7305E. 8GB RAM Processor Intel® Celeron® 7305E Graphics Intel® Iris® Xe Graphics VPU Optional (via M.2 2280) Memory 8GB eMMC / Storage via SATA or M.2 2280 NVMe* FPGA Lattice BIOS UEFI

UP Squared i12. Intel® Core™ I5-1240P. 8GB RAM Processor Intel® Core™ i5-1240P Graphics Intel® UHD Graphics for 12th Gen Intel® Processors VPU optional (via M.2 2280) Memory 8GB eMMC / Storage via SATA or M.2 2280 NVMe* FPGA Intel® FPGA Altera Max V BIOS UEFI

UP Squared Pro Pentium Quad Core 08/64 Processor Intel® Pentium® N4200 Graphics Intel® HD Graphics 505 VPU Optional (via M.2 2280) Memory 8GB eMMC / Storage 64 GB FPGA Intel® FPGA Altera MAX 10 BIOS UEFI Compatible OS Microsoft Windows 10 full version, Linux (Ubuntu, Yocto)

UP Squared Pro Pentium Quad Core 04/32 Processor Intel® Pentium® N4200 Graphics Intel® HD Graphics 505 VPU Optional (via M.2 2280) Memory 4GB eMMC / Storage 32 GB FPGA Intel® FPGA Altera MAX 10 BIOS UEFI Compatible OS Microsoft Windows 10 full version, Linux (Ubuntu, Yocto)

UP Squared Pro Celeron Duo Core 04/32 Processor Intel® Celeron® N3350 Graphics Intel® HD Graphics 500 VPU Optional (via M.2 2280) Memory 4GB eMMC / Storage 32 GB FPGA Intel® FPGA Altera MAX 10 BIOS UEFI Compatible OS Microsoft Windows 10 full version, Linux (Ubuntu, Yocto)

UP Squared 6000 AT 08/64Processor Intel Atom® x6425RE Graphics Intel® Graphics GEN 10 32EU 400Mhz (750Mhz with Turbo enabled) VPU Optional (via M.2 2280) Memory 8GB eMMC / Storage 64 GB BIOS UEFI Compatible OS Windows 10/10 IoT Core、Linux: Ubuntu 20.04、Yocto 3.1

UP Squared 6000 AT 04/32 Processor Intel Atom® x6413E Graphics Intel® Graphics GEN 10 16EU 500Mhz (750Mhz Turbo) VPU Optional (via M.2 2280) Memory 4GB eMMC / Storage 32 GB BIOS UEFI Compatible OS Windows 10/10 IoT Core、Linux: Ubuntu 20.04、Yocto 3.1

UP Squared 6000 PT 04/32 Processor Intel® Pentium® J6426 Graphics Intel® Graphics GEN 10 32EU 400Mhz (850Mhz Turbo) VPU Optional (via M.2 2280) Memory 4GB eMMC / Storage 32 GB BIOS UEFI Compatible OS Windows 10/10 IoT Core、Linux: Ubuntu 20.04、Yocto 3.1
